DX CONNEXION

The Morley-IAS DX Connexion panel is ideally suited for use in the protection of small to medium sized systems, It is high performance, feature rich, economical fire alarm control panel designed to help both - the installer and the end user.

• DXc1, Single-Loop Control Panel
• DXc2, Two-Loop Control Panel
• DXc4, Four-Loop Control Panel

ZXSe Series Control Panels

ZXSe range of analogue addressable fire alarm control panels have been designed and structured around proven and reliable microprocessor technology. This simple approach has produced a modular, Scalable fire alarm platform suitable for protecting all types of premises.

• ZX1Se - Analogue addressable fire alarm control panel
• ZX2Se - Analogue addressable fire alarm control panel
• ZX5Se - Analogue addressable fire alarm control panel

Repeaters & Interfaces

The repeater provides an extension to the operation of the fire alarm control panel. There are two types available - passive with indications only and no controls, or active with both controls & indicators.

• Active Repeater Panel
• Passive Repeater Panel
• 4-Way Relay Module
• 4-Way Sounder Module
• 8-Way Input Module
• 40-Way Mimic Interface Module
• Modbus Interface Module

Smoke, Thermal and Multi-Criteria Detectors

A completely new optical chamber design is proven in extensive testing ,to be more efficient, less liable to false alarm due to dust and insects and less susceptible to fault in high air velocities or back pressure.

• Optical Smoke Detector with & without Isolator
• Photo-Thermal Multi-Criteria Detector with & without Isolator
• Rate of Rise Thermal Detector with & without Isolator
• 58° Thermal Detector with & without Isolator
• 78° Thermal Detector with & without Isolator
• Photo-Thermal IR Multi-Criteria Detector with & without Isolator

Sounder Strobes

• Wall mounted sounder, Red
• Wall mounted sounder strobe
• Wall mounted Strobe
• Integrated Detector Base Sounder Strobe

Horn Strobes

• Wall Mount Horn-Strobe
• Ceiling Mount Horn-Strobe
• Mini Horn

TCP/IP Interface

The DIN rail mounted TCP/IP interface is designed for industry. It can be powered from two seperate supplies and handle an operating voltage range of 10-60 VDC. It provides comprehensive diagnostic tools for fault finding. The unit offers 10 LED indicators as well as advanced protocol diagnostics through Telnet support.

Optical Fibre Interface

Fibre optic cable is completely immune to external interference, which makes this unit ideal for harsh industrila environments. Another reason may be the need for a high level of security as fibre optic cable is very hard to tap. The fibre optic interface can handle data rates up to 1.5 Mbit/s. It is suitable with fibres with 820nm wavelength.

Visualeyez

Visualeyez is a pictorial and testual aid to help you mange an alarm activation within your work place. It can be programmed to suit any application including: Hospitals, Universities, Prisons, Hotels, Industrial and Commercial buildings. Visualeyez is designed to present the information in a simple , clear & user friendly way, allowing rapid comprehension of the situation.

In addition to the basic function of displaying alarms at a common location, the system also offers the ability to record and analyse both alarms and non-alarm events. This provides the building's engineers or management with the tools they need to analyse alarms, faults, review events, assess problems & plan their maintenance and false alarm prevention strategies.

Manual Call Point

• Manual Call Point

Modules

• Single Channel Input Module
• Dual Channel Input Module
• Dual Input Single Output Module
• Single Channel Output Module
• Short-Circuit Isolator Module
• Micro-Monitor Module
• Conventional Zone Monitor Module
